This Teammachine SLR Carbon frame and fork has been created with TCC Race technology, a D-Shape Carbon seatpost, Stealth Dropouts and comes ready to take internal cable routing.
This Teammachine SLR Carbon frame and fork has been created with TCC Race technology, a D-Shape Carbon seatpost, Stealth Dropouts and comes ready to take internal cable routing.
Bmc

2023 BMC Teammachine SLR V1 Frameset in Carbon/Prisma

£2,100.00
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2023 BMC Teammachine SLR V1 Frameset in Carbon/Prisma

Brand:Bmc

Code:BMC23TMSLRFRSV1CBN

This Teammachine SLR Carbon frame and fork has been created with TCC Race technology, a D-Shape Carbon seatpost, Stealth Dropouts and comes ready to take internal cable routing. The platform of choice for those looking to benefit from this bike's proven performance while building their dream Teammachine.

Frame

Teammachine SLR Carbon with Aerocore Design
Stealth Dropout Design
TCC Race Compliance Level
PF86 Bottom Bracket
Flat Mount Disc
12x142mm Thru-Axle
Optimized for Aerocore Bottle Cages

Fork

Teammachine SLR Carbon
TCC Race Compliance Level
Internal Cable Routing
Flat Mount Disc
Stealth Dropout Design
12x100mm Thru-Axle

Seatpost

Teammachine SLR Carbon D-Shaped Seatpost
15mm Offset

Tire Clearance

30mm (Measured Width)

Weight Limit

110 Kg

ASTM Classification

Level 1


Technical Information

Frameset

  • Teammachine SLR ACE carbon frame with Aerocore design, Tuned Compliance Concept Race
  • Teammachine SLR ACE carbon fork with Aerocore design, Tuned Compliance Concept Race
  • Teammachine SLR ACE carbon D-shape seatpost

Teammachine SLR features classic, round steerer forks. Models equipped with ICS stems use dedicated components that are adapted for use on round steerer forks.*


Technical Details

  • Aerocore: aerodynamic featherweight carbon bottle cage system (available upgrade)
  • Downtube bottle cage
  • Seat tube bottle cage
  • Internal cable management
  • Integrated seat clamp
  • Easy access Di2 junction box integrated in downtube
  • Stealth droputs with dedicated stealth thru-axles
  • ASTM level 1

Only use stealth thru-axles provided with Teammachine SLR01 and Teammachine SLR bikes and modules. Stealth dropouts and thru-axles are compatible with most direct-drive indoor trainers.*

Sizes

47, 51, 54, 56, 58, 61

Frame Weight**
990 g

Fork Weight**
375 g

Seatpost Weight**
195 g

Compatibility

Frame, Fork and Seatpost

  • Tapered fork with round 1-1/8" steerer, flat mount
  • Compatible with electronic and mechanical groupsets
  • PF86 bottom bracket
  • D-Shape seatpost
  • Braze-on front derailleur mount
  • Replaceable ultra light sandwich rear derailleur hanger

Brakes

  • Front brake: flat mount, 160 mm rotors only
  • Rear brake: flat mount, 140/160 mm rotors

Wheels and Axles

  • Designed for 25 mm, maximum tire clearance 30 mm (actual measured width)
  • Front stealth thru-axle: 12x100 mm (diameter/frame spacing)
  • Rear stealth thru-axle: 12x142 mm (diameter/frame spacing)

*Notes about proprietary technology

**Weight for the lightest finish, including complete hardware with size 54 frames
